Cremation incinerator C1000

for microbiologybacteriologicallaboratory

The Addfield C1000 is a modern clinical waste incinerator designed to burn solid waste in a clean and environmentally safe manner. Using the pyrolytic principles of combustion, the C1000 model has been specifically designed for burning clinical waste from hospitals and research centres at a rate of up to 1000kg/hr. The machine is equipped with the necessary control systems, a primary and secondary after chamber with a two second residue time. The machine is available with an automatic bin tipper system, automatic ram charging system, vertical opening door, automatic de-ashing and gas cleaning equipment to satisfy the most stringent environmental standards. The primary combustion chamber arrangement is a multiple stepped hearth refractory, with waste loading taking place at the highest level. Each hearth has an evacuation ram to manoeuvre the residue through the chamber and finally into the ash treatment zone. This design enables continuous operation during a 24 hour period with automatic ash removal during the cycle. Only with this stepped hearth arrangement can a high capacity burn process happen. The movement of waste throughout the machine removes any potential cold spots, agitated the waste and allowing for an immensely high combustion efficiency. Manufactured in Britain, to an extremely high standard, the machine uses heavy gauge steel work and a multi-layers brick lined refractory for maximum efficiency. The C1000 machine is suitable medium to large hospitals to very large hospitals The machine would be able to service the equivalent of up 3800-9,600 beds.
