Dust collector for the pharmaceutical industry G series

mobilewith filtration system

No cost of maintenance thanks to the automatic compressed air cleaning system of the cartridges Efficiency filtration up to 99.9% (residual penetration ≤0,1%) Extremely quiet for its category thanks to the built-in silencer Filtered air recirculation in the environment with consequent energy saving REQUEST AN ESTIMATE Cartridge dust collectors for intensive use without maintenance The G series dust collectors are available in two basic models: GH, standing dust collector provided with horizontal cartridges that is distinguished by its extreme compactness; GV, fixed dust collector provided with vertical cartridges that allows an easy cleaning of cartridges also in the presence of very difficult pollutants, binding agents and adherents. The dust collectors are available in different models, with nominal capacities ranging from 450 Nm3/h up to a maximum of 10,800 Nm3/h. They are equipped with a filtering system provided with polyester cartridges with a large filtration surface ensuring a maximum efficiency equal to category M according to DIN EN 60335-2-69 (Safety of electrical appliances for household and similar use – Part 2: Particular requirements for vacuum cleaners and industrial vacuum cleaners). The wide choice of the filter media makes their use suitable for various kinds of pollutants. Absolute filters (H13 and H14 efficiency) and/or active carbon filters can be added. The G series dust collectors are finally available in different special versions, including those of AISI 316 stainless steel or those of ATEX II 3 D currently in use.
