• Oil-free one-stage piston compressors aluminum and WCB steel cast made, aluminum pistons for a maximum working pressure of 100 PSI (Compressor is NOT continuous - duty), arigmed brand with transmission by pulleys and bands with electric motor 220v 60htz; (must specify in advance to the factory).
• (OPTIONAL) Two-stage Oil-Free Piston Compressors aluminum and WCB steel cast made, aluminum pistons for a maximum working pressure of 160-170 - PSI - (Compressor is - NOT
continuous duty). arigmed brand with pulley transmission and bands with electric motor 220v 60htz; (must specify in advance to the factory).
Air Refrigerated AfterCoolers:
• Air Refrigerated Aftercoolers guard belt type, includes a multiple connection block with relief, backflow and automatic valves for each compression unit.
Air Vessel:
• Air vessel under ASME spécification with internai and external treatment (may include a man access hatch for maintenance and internai cleaning).
• ASME stamped is not inlcuded in this air compressor system.
Control Panel:
• Electrical-electronic control panel to coordinate alternation, simultaneous use and stop, as well as the control of the Régénération Air treatment system.
Regenerative Tower Air Dryers:
• Regenerative tower dryers, with Normally open electric valves timed and controlled by the equipment control panel, drying température of -40°c.
Systems Included:
• Automatic valve Systems to prevent back flow
• High température détection system
• Automatic valve system for moisture purges
• AIR DRYING System twintower regenerative type
• AIR FILTRATION System
Compressor Power:
• 5 HP
• 7.5 HP
• 10 HP
• 15 HP
