Friction Free Lumbar Section Seperates 5″ and rolls on 4 Steel Ball Roller Bearings. The Rolling Section can be locked in any position with a positive gear rack system.
Top Section: Four Piece
Width: 27″
Length: 76″
Overall Length: 99″
Head Section: One Section
15″ x 27″ Raises 45 Degrees. Lowers 90 Degrees. Contoured Face / Nose opening.
Center Section: 10″ x 27″
Thoracic Section: 18″ x 27″
Foot Section: 33″ x 27″ Raises 80 degrees.
Lifting Capacity (lbs): 400
Heavy duty steel tube Hi Lo control allows adjustment of the table height while keeping both hands on the patient and both feet on the floor. The control is designed to allow easy access from anywhere around the table without disrupting the treatment.
Minimum Height : 18″
Maximum Height : 37″
Heavy-duty vinyl with bacterial protection.
1.5″ Firm density foam tops.
Radiused, seamless corners on upholstered components.
Top sections have welded steel support frames.
Pivoting joints house hardened steel shoulder bolts to ensure years of trouble-free operation.
4 Caster Base with 4″ Total Lock ball bearing casters
110 volts, 60Hz motor (220 volts, 50 Hz available on special order).
