Vortex laboratory stirrer LG-9590-104
overheaddigitalcompact

Vortex laboratory stirrer - LG-9590-104 - ATS Scientific Products - overhead / digital / compact
Vortex laboratory stirrer - LG-9590-104 - ATS Scientific Products - overhead / digital / compact
Add to favorites
Compare this product


Characteristics

Type
overhead, vortex
Display
digital
Configuration
compact
Rotational speed

Min.: 40 rpm
(251 rad.min-1)

Max.: 2,010 rpm
(12,629 rad.min-1)

Description

This stirrer delivers 50% more power than the CompactDigital™while keeping the same compact footprint,Stirlight™and through shaft. It works smarter and allows the user complete mixing control. Stirring direction can be changed with the touch of the reversing button. The countdown timer monitors a stirring activity and beeps when completed. InxRxmode the stirrer will continuously reverse from one direction to the other for a set length of time. Each model includes chuck, chuck key, mounting support rod, external power supply and grounded power cord. Clamp, stand and impellers are available. Features include: Countdown Timer : Repeatable, accurate results; Stirring stops when time is complete Reversing: Mixes in clockwise or counterclockwise direction; Offers different mixing with the same impellers xRxAgitation: Controllable vortex effect; Quicker, more complete mixing; Eliminates air from sample Brushless DC Motor : 50% more power; Maintains speed at all viscosities; Automatic overload protection Stirlight™ : Shows stirring clearly; Monitors mixing properties of batches Through Shaft : Impeller adjustment made easy; Less down time due to impeller changes Specifications Description:ReversingDigital™ Stirrer Maximum Torque:100 N•cm LED Display Accuracy:+/- 1 rpm of 3% of reading (4 digit) Elec. Output Power Supply to Stirrer:DC 24 V, 4.75 A, 90 W Max Mechanical Output Power:1/10 hp, 70 W (Brushless DC Motor) Input to Power Supply:AC 100-240 volts, 50/60 Hz**
