Raman spectrometer Exemplar Plus LS

fluorescenceNIRUV

The Exemplar® Plus LS is a high performance smart spectrometer utilizing an aberration corrected concave holographic grating, to minimize stray light. Its long focal length, coupled with a high quantum efficiency detector, provides superior data quality over the entire 190-1100nm spectral range. The Exemplar Plus LS features a high signal to noise ratio, making it ideal for low light level applications, and also features a built-in shutter allowing for dark scan measurements, even while illuminated. As a member of the Exemplar product line, it features on board data processing and USB 3.0 communication. The Exemplar product line is also optimized for multi-channel operation featuring ultra-low trigger delay and gate jitter. Standard spectral configurations range from 180nm - 1100nm and resolutions range between 0.6nm and 6.0nm. Custom configurations are available for OEM applications. Applications: Low Light Level UV to NIR Spectroscopy Raman and Fluorescence Spectroscopy On-line Process Monitoring LCD Display Measurement BioMedical Spectroscopy Gas and Water Analysis LED Characterization Features SMART: On-board processing including averaging, smoothing, and dark compensation SPEED: Acquires and transfers more than 140 spectra per second at an integration time of 6.3ms SYNCHRONOUS: Supports up to 32 devices with ultra-low trigger delay (95ns) & gate jitter (+/- 20ns) Additional Features: 2048 Detector Elements Over 60% QE at 200nm Configurable Cooling Temperature (0° Default) 80% peak QE Built-in Shutter Ultra Low Stray Light Specifications Power Input - 5V DC @ 3.0A (Maximum at Startup) Detector Type - Back-thinned CCD Array
