Product feature:
● 24 hours Parametric trend diagram display;
● Audible & Visual Alarms: power failure, sensor failure, higher & lower temp, air & skin temperature override, fan failure, low water level, system failure;
● >37℃ Preset Mode: power failure reset memory,alarm silence, self-test function;
● Hood with single slope, big front door, 6 access ports, 4 tube grommet;
● 2 Storage cabinets, Protective guard rail, IV poles;
● RS-232 Output Connector (use for network system);
1 . Air temperature:
Air temperature display range: 0℃-60℃;
Air temperature control range: 20.0℃-37.0℃, 37.1℃-39.0℃
Air temperature accuracy: ≤±0.3℃;
Air temperature deviation alarm: ±3.0℃.
2 . Skin temperature:
Skin temperature display range: 0℃-60℃;
Skin temperature control range: 20.0℃-37.0℃, 37.1℃-38.0℃;
Skin temperature accuracy :≤±0.3℃;
Skin temperature deviation alarm: ±1.0℃.
3. Humidity
Humidity display range: 0%--99%RH;
Humidity control range: 30%--95%;
Humidity control accuracy: (10% - 90% at 20 - 40℃)±5%RH.
4. Oxygen concentration (Optional)
Oxygen concentration setting range: 21%-65%
Oxygen concentration display range: 18%-99%
Oxygen concentration display accuracy: 2%
Oxygen concentration control accuracy: 3%
5. Baby weight scale(Optional)
Weight range: 500g-10kg
Weight accuracy: ±10g
Display trend diagram of baby weight
6. Pulse Oximeter monitor (Optional)
SpO2: measure range 0-100%, display resolution 1%;
Pulse rate (PR): measure range 25-250bpm, display resolution 1bpm;
Perfusion index(PI): measure range 0-20%, display resolution 0.001%;
Variability index: measure range 0-100%, display resolution 1%
