Cardiovascular disease POCT analyzer 0055HC

for inflammatory diseasesfertilityfor cancers

ACT99 Plus: Lab closed to the patient Advantages: a. Compact and Liquid POCT b. 8 assays within 15 mins c. Singal test cartridge Chemiluminesence Immunoassay d. Test menu: Cardiac, Infection, Thyroid, Tumors, Reproductive, Gastric function, etc. Parameters: Test speed: ≤ 32T/H Test mode: 1. One-step method 2. Two-step method, one separation 3. Two-step method, two separations Reaction principle: Sandwich method, indirect method and competition method Performance Index: a)Reagent and sample loading volume: 10~150μL, in increments of 1μL; b)The temperature control bias of the reaction sections should be within 37.0℃±0.5℃, and the fluctuation should not exceed 0.5℃; c)Linearity of luminous value: Linear correlation coefficient (r)≥0.99; d)Repeatability of luminous value: Coefficient of variation (CV) should not exceed 5%; e)Stability of luminous value: Change of luminous value should not exceed ±10%; f)Carrying pollution: 0. Other Functions and LEDs: Number of reaction channels: 8 channels; Computer: Built-in computer, WINDOWS system; Printing: Built-in thermal printer; Code scanning: Built-in sample and reagent scanning module; Minimum sample size: 10μL; Size and Weight: Volume (W*D*H): 228*385*256mm Weight: 12kg
