• Speed range 0.3-35km/h
• Front elevation 0 to 25%
• Rear elevation -25 to 0% Optional
• Running surface 190x65cm
• Max user weight 200kg
• Power requipments AC230V 50Hz 12A(2 phases) Motors 3kW (4HP, Pick 8HP)
• Interface 2xRS232 , USB
• Dimensions 240x87,6x120cm (height with display 150 cm)
• Weight 195kg
• Environmental conditions Operational: - temperature 15 to 40 Celcium - humidity (non-condensing) 30 to 90% -air pressure 70 to 1001cPa
Storage: - temperature - humidity (non-condensing) -air pressure
• Safety Standards
15 to 40 Celcium 30 to 90% 70 to 100kPa
EN ISO 957.1/ EN ISO 957.6 EN 60601-1,-2 CLASS SA CE Standard, Stop button Optional Optional Standard Optional Optional
• Emergency stop
• Heart rate
• Entrance plate
• Anti-slip strips
• Fixed side handrails
• Adjustable side handrails
Heigth 750 to 950mm Width 450 to 950mm
• Adjustable pediatric front handrail Optional Heigth 550 to 750mm
• Adjustable pediatric side handrail Optional Heigth 550 to 750mm Width 450 to 950mm
• Safety belt and fail-stop Optional
• Control panel
15"touch screen(LCD) with manual mode and pre set programs,heart rate controlled workload,calculate,distance and calories. Digital display of speed,elevation,distance,total time.
