LED microplate reader S6 Micro M2

ELISAfor protein quantification384-well

This model’s optical resolution is designed for image analysis in the microscopic spectrum. Single cells, organelles, and intracytoplasmic organisms can be detected and counted in microtiter plates; however, this instrument’s motorized zoom optics also extend the field of analysis into the macroscopic range, in larger well formats. The S6 Micro M2 is high-throughput capable – up to 400 plates per run when equipped with our automated plate loader. It is specifically designed for regulated or academic visible light, including multi-color white light analysis, supporting 21CFR part 11 compliant workflows Specifications Applications Single and Double-Color ELISPOT Viral Infectivity and Neutralization Assays, e.g.: FRNT / FRA PRNT / Viral Titer Assays Bacterial and Yeast Colony Counting 12 Distinct Visible Light Color Planes ELISA Nucleic Acid and Protein Quantification Visible Array Analysis Plate formats 24, 48, 96, 384, 1536 and Teraski Strip plate in 96 well format (upgradable to rapid 6/Petri) Advanced Components Precision stage (0.24 mm stepping) Digital area scan camera with image resolution of up to 25 Megapixels Computer Interface: USB 3.0 Integrated Barcode Reader Optical Interface: Motorized zoom and focus Lighting Top: 114 LED Ring (rated for 100,000 operating hours) Lighting Bottom: High illumination, uniform luminescent flat light panel Data processing features Dell Optiplex SFF computer CPU: 8-core i7; Memory: 16GB RAM, Graphics: Intel HD Storage: 500 GB + 1TB GB (System + Data); Optical Drive: Slimline DVD+/-RW Ports: 1x Serial, 1x USB 3.1 Gen 2 Type-C, 4x USB 2.0 Type A, 5x USB 3.1 Type A, 1x Ethernet, 1x DP
