Platinum Palladium HC system to completely remove the HCT for an absolutely stable,
noise-free base line High efficiency end filter to remove residual CO2
Ready to be connected to the dedicated AirComp compressor
Possible parallel connection up to 4 stackable tower configuration generators
CPU with Touch Screen Display that can be linked to the generators with CAN-BUS, allowing monitoring of the operating status and menu reading with the maintenance status, the alarm report and functional parameters
Technical specifications
FLOW RATE - 1500 NmL/min ± 10% a 2000 m slm
TECHNOLOGIES EMPLOYED - PSA + catalitic reactor Pl/Pd
PURITY - HCT < 0,1 ppm
CO2 residual < 1 ppm
MOISTURE - < -70 °C dew-point ATP ± 2°C ATP
AIR INPUT CHARACTERISTICS - Particulate ≤ 0,01 mm
Oil vapors ≤ 0,01 mg/m3
Moisture ≤ 3° C dew point ATP
min pressure: bar/115 psi
Air flow rate: 8 Nl/min
ELECTRICAL SUPPLY - 115 Vac ±10% 60 Hz 250W
230 Vac ±10% 50 Hz 250 W
INDEX OF PROTECTION - IP20
NOISE - < 50 dBA for the 98% of operation time
< 60 dBA for 2 sec. each cycle
OPERATING TEMPERATURE - 5°C fino 35°C (41°F fino 95°F)
ENVIRONMENTAL HUMIDITY - max 90% without condensation
MAX ALTITUDE - 2000 m slm
DIMENSIONS - Height: 40 cm + 7 cm/15.8” + 2.8”
Width: 38 cm/14.9”
Depth: 53 cm/20.8”
WEIGHT - 28 kg/62 lbs
PNEUMATIC CONNECTIONS - Compressed air inlet: G 1/8” female
Purified air output: G 1/8” female
