Medical air compression system L02
screwlubricated

Add to favorites

Compare this product

Characteristics

Applications

medical

Technology

screw

Options and accessories

lubricated

Pressure

10 bar
(145.04 psi)

Flow

0.21 m³/min, 0.36 m³/min, 0.53 m³/min
(7.42 ft³/min, 12.71 ft³/min, 18.72 ft³/min)

Max.: 0.89 m³/min
(31.43 ft³/min)

Min.: 0.18 m³/min
(6.36 ft³/min)

Power

2.2 kW, 3 kW, 4 kW
(2.99 hp, 4.08 hp, 5.44 hp)

Max.: 7.5 kW
(10.2 hp)

Min.: 2.2 kW
(2.99 hp)

Weight

Max.: 364 kg
(802.5 lb)

Min.: 151 kg
(332.9 lb)

Noise level

Max.: 70 dB

Min.: 63 dB

Length

Max.: 1,885 mm
(74.2 in)

Min.: 600 mm
(23.6 in)

Width

720 mm
(28.3 in)

Height

Max.: 1,700 mm
(66.9 in)

Min.: 1,100 mm
(43.3 in)

Description

To meet the requirements of the individual customer demands the range of compressors can be combined with numerous options to provide everything from a stand alone compressor, receiver mounted or complete Airstation including refrigerant dryer. In addition to the existing benefits of the previous 2 to 5 kW range, the new models offer the following improvements based on extensive research and development combined with customer feedback from the field: Auto tensioning of the drive belt New C-Pro1.0+ Controller Improved servicing capability with new canopy design Extended models with integrated after cooler Motor overload protection Airend protection New 7.5 kW variant New group of dryers (our own downstream equipment) New airstation design with AD 2000 receivers as standard Designed with the minimum number of moving parts, these compressors are reliable, robust and capable of continuous running for numerous applications. They are easy to use, easy to install and fully ready for plug and play.With fully removable side panels the compressor is quick and easy to maintain and service, minimising downtime and maximising reliability. Thanks to the fully removable side panels, these compressors can be serviced quickly and easily, which minimizes downtime and maximizes availability.
