Medical control unit CU20

Up to four analogue drives and one handset can be connected to the CU20 control unit. Up to three drives can be connected when using an optional integrated SMPS. This very compact control unit from Dewert can be mounted directly on the Megamat20 single drive or separately in the system. Due to its excellent price-performance ratio and versatility, the CU20 is perfectly suited for demanding applications in the medical sector. The standard high degree of IP67 protection persistently prevents the ingress of foreign bodies, while enabling safe and hygienic cleaning of the components. Duty cycle 2/18 min. or 10 %, max, 5 switching cycles per minute Control unit Direct switched Output voltage 29 V DC constant Housing colour light grey RAL 7035 Safety Single-fault protection SMPS yes Connectivity Up to 4 analog actuators (3 with integrated SMPS), 1 hand control Protection type IP67 Protection class II/III Relative humidity 30% – 75% Ambient temperature +10°C - +40°C Power supply 29 V DC (without SMPS), wide input voltage range 100-240 V AC (with SMPS) Safety single-fault protected Assembly options fastening drill-holes/direct fixing to Megamat 20 Connection options Up to 4 analog actuators without SMPS, up to 4 analog actuators with integrated SMPS
