Operating room door 104.04

swingglassdouble

Together with the casing, this metal revolving door represents one of the basic elements to construct clean workplaces and areas with maximum safety, sterility, hygiene, easy maintenance and sanitation. Facing The facing of the door leaf consists of a molded tile produced by precision molding. Reinforcements are glued-in along the perimeter of the facing, in order to increase the rigidity of the door leaf. Reinforcement and filler are glued together under pressure. Door wing The door leaf is solid or glazed with the PHARMA system, offering double-sided glazing where the glass pane is in plane with the surface of the door leaf. It is possible to install blinds in the space between the glass panels. Casing Mounting into the modular partition. Casing is in line with partition. Magnetic locks - tongue extends until closing and no damage to casing the paint. Swing direction left right Finish single wing double wing Door dimensions 1100x2010 1300 x 2010mm (active wing width 900mm) 1500 x 2010mm (active wing width 900mm) 1700 x 2010mm (active wing width 900mm) 700x2010 900x2010 In the case of an atypical active door wing, it is necessary to specify the dimensions of the active wing as part of the code. For example 1800/900/x2010 (clear width 1800, active wing 900, passive wing 900).
