Sliding panel 102.08

The X-ray partition panel is the main element to construct clean workplaces and areas with protection against X-radiation. It does not visually differ from standard partition panels. The panels are connected to each other by means of a slide-on connection; a shielding connecting lead insert is inserted in the panel joint which, providing for a perfect overlap of panel joints with the shielded element. The thickness of the lead shielding insert is always determined by the designer, based on radiation optimisation and radiation limits according to the implementing regulation on radiation protection, in accordance with applicable regulations in each country. Thickness of shielding lead insert 1 mm 1.5 mm 2 mm 3 mm Panel thickness 100 mm 120 mm 60 mm 80 mm Panel width W width - value 500 mm - thickness of lead insert 1; 1.5; 2 and 3 700 mm - thickness of lead insert 1; 1.5 and 2 900 mm - thickness of lead insert 1 and 1.5 For S2 1 and 1.5: W - width in mm according to dimensional range Preferred dimensions: - max 900 mm For S2 2: W - width in mm according to dimensional range Preferred dimensions: - max. 700 mm. For S2 3: W - width in mm according to dimensional range Preferred dimensions:- max. 500 mmFor a shielding insert with a thickness of 2 and 3 mm, the maximum width is 800 mm. It is possible to order atypical panel dimensions: min. dimension 300 mm, max. dimension 1190 mm. W - width in mm according to dimensional range 500, 700 and 900 mm. Panel height H 2550 mm 2750 mm 3050 mm H - height in mm according to dimensional range. Preferred dimensions 2550, 2750, 3050 mm, min. dimension 300 mm, max. dimension 4000 mm.
