Steel panel 102.11

The above-door partition panel is a panel that complements the basic panels and is used above door in the partition system Forclean. Panel type basic partition panel - above-door Panel thickness 100 mm 120 mm 60 mm 80 mm Panel width W 1020 mm 1220 mm 1420 mm 1620 mm 1820 mm 820 mm Panel height H 1030 mm 530 mm 730 mm Side end groove - tongue tongue - tongue groove - straight groove - groove straight - tongue Bottom end basic+reinforcement clasic+simple reinforcement clasic+reinforcement atypical Upper end clasic (straight) clasic (straight) atypical no upper bend (high panels) Number of cable glands no cable gland 2 pcs (1 pc 85 mm from the left - 1 pc 85 mm from the right) cable glands from the left, cable glands from the right Filler Mineral wool PSE - foam polystyrene Atypical Facing hue and material - standard on the visible side Galvanized metal sheet, hue RAL 9002 Galvanized metal sheet, hue RAL 9016 Stainless steel AISI 304 Aluminium sheet, hue RAL Galvanized metal sheet, hue RAL Facing hue and material - standard on the rear side Galvanized metal sheet, hue RAL 9002 Galvanized metal sheet, hue RAL 9016 Stainless steel AISI 304 Aluminium sheet, hue RAL Powder coating (Komaxit), hue RAL Atypical design Type design Atypical design Type design 0 - Unique specification out of offered versions Atypical design Q - atypical design that cannot be uniquely specified by a code
