Pneumatic leak tester T6990

for medical devicescompactUSB

T6990, recalculating the success of its predecessor M6990, an obviously enhanced user interface, thanks to an innovative tempered glass panel with built-in capacitive keyboard, around a 3.5” colour display. The new, high resolution display makes it even easier to view the test cycle and the programming menus, and the capacitive keyboard allows fast parameter entry. T6990 has a more limited port supply than high level range, but is equally complete: a USB slave port, RS232, RS485 and Can bus. The front panel has a master USB port for connection to a USB key to save the tests conducted, backup/restore parameters and upgrade tool firmware. The connection to thermal printers, barcode/data-matrix readers and markers takes place automatically using an internal menu. T6990 can count on a measurement resolution of 0.1 Pa to 1 bar (0.5 Pa to 6 bar) stable and noise-free, sharing a part of the measurement section implemented on the higher series T8000 and T9000. Despite being designed as an entry-level tool, the measurement performance is absolutely comparable to those of the rest of the ForTest range. T6990, to keep dimensions as compact as possible, assembles a pneumatic unit with standard valves, ideal to test volumes up to 5 litres. The robustness of these valves means no scheduled maintenance of any kind is necessary, therefore guaranteeing
