Mobile C-arm Aria

with video columnwith integrated video monitor

The first C-arm with veterinary medicine dedicated software, ideal for surgical, vascular and orthopaedic applications Innovative for its reduced mechanical dimensions and compact size and for its high frequency generator with radiation shielding. FEATURES Double highdefinition LED monitors Integrated DICOM solution 1k x 1k High Resolution Technology Touch screen console Microprocessor controlled High Frequency Generator Hermetically sealed Normal/High Level Fluoroscopy Exposure foot switch Wheel lock TECHNICAL FEATURES X-Ray Tube Type: Stationary Anode Nominal Focal Spot Value: 0,6/1,8 - IEC60336l Mode of Operation: Fluoroscopy, Radiography Dimensions (Lxlxa): 500 x 488.5 x 15.0 mm kV Range: 40 - 110 kV Maximum Output in Large Focus: 3,5 kW (220 - 240 VAC) Maximum tube current Large Focus: 70 mA @ 50 kV, 32 mA @ 110 kV mA Range for Continuous Fluoroscopy: 0,2 to 8 mA mA Range for Pulsed Fluoroscopy: 0,2 to 12 mA Digital Snap Shot: 0,2 to 10 mA Immersion Depth: 26,34'' (670 mm) Clear space (free space): 30,31'' (770 mm) Vertical Travel: 17.71” (450mm) Horizontal Travel: 7.87” (200mm) Orbital Motion: -40° to 90° Max
