3-way infusion manifold AV0022

intensive care

Standard 22mm port for the monitoring or collection of expired gases through a scavenging bag Resistance: < 1.63 cmH2O @ 60 LPM Polysulfone for all connector and housing, which is autoclavable at 134°C The 3-Way Manifold is attached to the single limb breathing circuit to regulate the expiratory valve. The control line from the ventilator controls the opening of the valve to enable air to flow in and out accordingly. This line intermittently provides the pressure needed to close the expiratory valve during inspiration, which blocks gas outflow during the application of inspiratory positive pressure.
