Medical air compressor ESK960/500piston
Add to favorites
Compare this product
Characteristics
- Applications
- medical
- Technology
- piston
- Pressure
10 bar
(145.04 psi)- Flow
480 l/min, 620 l/min
(126.8 us gal/min, 163.79 us gal/min)- Power
6 kW
(8.16 hp)- Weight
340 kg
(749.6 lb)- Noise level
77 dB
- Length
2,040 mm
(80.3 in)- Width
670 mm
(26.4 in)- Height
980 mm
(38.6 in)
Description
Condensate Treatment - Optional
Particulate Treatment - -
Air purity class (ISO 8573-1) - X-X-0
Voltage (V) - 400,00
Frequency (Hz) - 50,00
Nominal rating (kW) - 6,00
Nominal rating (HP) - 8,00
Rotation speed (rpm) - 1.400,00
Starting current (A) - 13,00
Number of cylinders - 8
FAD (L/min) - 960,00
Air Delivery (L/min @5 bar) - 620,00
Air Delivery (L/min @8 bar) - 480,00
Maximum pressure (bar) - 10,00
Noise level (3,00m @ 5,00 bar (dB(A)) - 77,00
Duty cycle - S1 100%
Tank Coating - Epoxy (internal/external)
Tank capacity (lt) - 500,00
First Maintenance (hours) - 3000
Hour Meter - Incluso
Tank Automatic Drain Valve - Optional
