Internal dimensions
L LENGTH16 9/16 in
W WIDTH11 13/16 in
D DEPTH3 3/4 in
LID1 3/8 in
BASE2 3/8 in
External dimensions
L LENGTH18 in
W WIDTH14 7/16 in
D DEPTH4 5/8 in
WEIGHT EMPTY4.85 lbs
WEIGHT WITH FOAM5.29 lbs
VOLUME3.17 gal
BUOYANCY14.99 lbs/max
OPERATING TEMPERATURE°F min -27.4 / max 194
New pull release latch grants additional safety and avoids accidental opening
SOFT GRIP HANDLE
Load tested handle, reinforced with corrosion proof steel pins
CORROSION PROOF METAL HINGES WITH LID STAY FEATURES
Additional fixing points on the lid, available on certain models
SEALING O-RING
LID CAN BE SET TO SLIDE-OFF
By releasing the back screw, lid becomes set to slide-off when opened at 70°
ABILITY TO STACK
The special design of the bottom and the lid feet, grants a perfect stackability.
METAL CLIPS
Clips metálicos reforzados en los principales puntos para candados
WRITABLE NAME TAG
PVC waterproof ID removable label
AUTOMATIC PURGE VALVE
Automatic pressure release valve.
Practical and robust lid panel with pouches, ideal for small accessories and documents. Suitable for
cases 4209 and 4216. Color: black.
CONVOLUTED FOAM SET FOR CASE 4209 AND 4216
LIDFOAM.42
(includes 2 pcs.)
