Liquid filter Cameo

for chromatographypolypropylenePTFE

Benefits Increased throughput and speed of sample preparation. Lower hold-up volume due to an improved flow channel design and reduced spacing between the supports within the housing for better handling of small sample volumes or costly samples. Increased operating pressure up to 130 psi due to the over-mold that prevents sample leaking at the seam and keeps the filter unit from bursting in half. Strict quality control: Syringe filters are integrity-tested to ensure a proper filter fit and weld to eliminate any potential filter by-pass. Accurate labeling: Each filter is labeled with the specific filter material and pore size for easy identification even if the syringe filter is not in its original packaging. Features Housing: Pure polypropylene is heat-sealed without the use of glues or sealants Media: Nylon, PTFE, PES, PVDF, glass fiber, cellulose acetate and polypropylene Autoclavable: Yes Prefilter: 1.0 micron binderless glass-fiber Filtration area: 4.8 cm2(0.74 inch3) Housing diameter: 33mm Membrane diameter: 30mm Holdup volume: < 60 microliter Sample volume: < 120 mL without prefilter Inlet/outlet: FLL-MLS Applications HPLC sample preparation Dissolution testing Content uniformity Environmental samples Composite assays Food analysis Biofuel analysis
