- Proline cabinet design
Strong body and front made from melamine
board incl. a 2 mm thick protection layer
and ABS edge strip, scratch- and waterproof.
Hygienic construction by smooth surfaces,
integrated formfitted hinges, double pressed
body with sealed and screwless connections
to perform reliability and durable function.
- Optimized dust protection thanks to 3mm edge
banding on the front of the body,
look: silver gray
- Decor: completely myosotis (C18)
- X-carriage with bumper protection function
polyethylene, all of a piece
- 4 special designed swivel castors, 2 with brake
wheel diameter 125 mm
tread: thermoplastic rubber, gray non-marking
ball bearing
caster housing: polyamide
- Cart dimensions: approx. 680 x 629 mm (W x D)
working height: approx. 1114 mm
.
left side, above:
- 1 push bar, stainless steel
left side, middle:
- 1 pair of universal hooks
for side storage accessories
right side, above:
- 1 fold down side shelf
dimensions: approx. 407 x 455 mm (WxD)
backside: accommodation for overbridge norm rail
.
Cabinet design from top to bottom:
- 1 drawer, height approx. 128 mm (2 HU)
Bow handle (BogengriffPlus) Stainless Steel look
- 1 drawer, height approx. 192 mm (3 HU)
Bow handle (BogengriffPlus) Stainless Steel look
- 1 cabinet with two leaf doors
height approx. 576 mm (9 HU)
Bow handle (BogengriffPlus) Stainless Steel look
left door with aluminium door stop band
door fixation by ball catch
aperture angle w/ - w/o accessories ca.180°/260°
- equipped with 1 shelf
(2 compartments)
- all drawers with full pullout, self-closing and
soft-close damping
