Medical check valve TLC 3

The directional spool valve type TLC is a combined design consisting of a directional spool valve and a releasable check valve. It can be used to hold hydraulic actuators in position for long periods of time. The built-in T-throttles allow the user to preset the speed of the actuators. The magnetic plugs used are IP65 connectors (AMP superseal) used in the automotive industry. Multiple directional valves can be combined in series in the valve bank type TLC. Combined with the compact hydraulic power pack type A10, this forms a minihydraulics system solution that requires little space and uses low flow rates up to 3 lpm. ■ Requires little space thanks to compact design ■ IP 65 connector (AMP superseal) Intended applications ■ Operating tables ■ Airline seats ■ Automotive (window lifters)
