Compact laboratory peristaltic pump Ultimate 120

Accurate dosing is particularly important in the pharmaceutical, cosmetic or food sector. Comprehensible process conditions are a prerequisite for the safe conveyance of sensitive media. This is ensured by a control accuracy of ±1% and precise speed adjustment (5 — 120 rpm). In addition, an optional foot switch allows the pump to be operated in closed exhaust hoods. The parameters - speed, direction of rotation and on/off function - can be controlled externally either through the analog or digital interface. In this model, you can choose between a single-channel or multichannel pump head. Flow rates vary depending on the pump head: the single-channel head has a flow rate of 0.38 — 813 ml/min; for the multi-channel head 0.005 — 364 ml/min. Depending on the focus of the process, the following parameters can be set on the device: Speed, tubing diameter, flow rate display, metering volume, interval dosing and break times. The pump can be calibrated for optimum dosing results. Multi-Channel Operation Increase your throughput by running up to 12 individual cassettes on one single pump drive and pump head system Separate metering into multiple vessels with different feed rates in a single operation by using different tubing dimensions to adjust flow rate Save time: tubing change is done in just seconds In addition to standard pump heads which feature a 4-roller system you can choose 8-roller pump heads for low pulsation
