Digital video microscope MSC-M4XC

for materials researchuprightbinocular

Optics - Finite Distance Optical System Observation Tubes - Tilting binocular, interpupillary 55-75mm Viewing Head - Seidentopf head, inclined at 30° Optical Coating - Transmittance ≥ 95% Eyepiece - WF10X/18mm, with scale of cross hair Objective - PL L10X/0.25  LWD 8.9mm PL L20X/0.40  LWD 3.75mm PL L40X/0.60  LWD 2.69mm SPL 100X/0.90 LWD 0.44mm *PL L50X/0.70  LWD 2.02mm *PL L60X/0.75  LWD 1.34mm *PL L80X/0.80  LWD 0.96mm *PL L100X/0.85  LWD 0.4mm Nosepiece - Backward quadruple  /Backward *Quintuple Stage - Double layer mechanical stage 180×150mm, moving range 15mm×15mm Focusing - Coaxial coarse and fine adjustment, fine division 2um *Software - *Grain size analysis software Illumination System 6V/20W halogen light, brightness adjustable Polarizer and analyzer Green, blue, yellow filter Electricity - 100-240V AC,50/60Hz Package Dimension (W*D*H) (mm) - 400×300×450 *Optional - Photo/Video attachment; Micrometer scale 0.01mm; Fluorescent attachment
