φ150mm vent
Piano hinges
Fireproof expansion seal meets the requirements of GB16807-2009
The inner side uses porcelain white PP plates
Description
1, There is a φ150mm vent in the middle of the cabinet top and an AC220V,50HZ, and 0.18A axial fan is disposed of in the vent.
2, Piano hinges are used to ensure that the door can open 180 degrees. A fireproof expansion seal is installed between the cabinet door and the cabinet and the seal meets the requirements of GB16807-2009.
3, The inner side (upper/lower/left/right liner panel) uses porcelain white PP (polypropylene resin) plates. The cabinet is disposed of with three one-time forming three-layer staircase type PP polypropylene resin movable shelves and 10mm vents are disposed on the shelves.
Specifications
Opening mode - Manual
Lock - Electronic combination lock with two locks
Plate - 3 PP staircase-type movable shelves
Others - Time control switch
