Surgical light battery IL-2217

compact

High Performance Variable 450 – 900 Watt Power Supply For DC Xenon Short Arc Lamps. The IL-2217 125-300W Variable Xenon Power Supply is a universal input, power factor corrected, current and power regulated power supply adjustable from 10 to 22 Amps. With a voltage range from 10 to 30 VDC, it provides a single source for powering any Xenon lamp from 125 to over 300 watts. The state of the art design provides for very high technical performance in a very compact unit. Its high efficiency (>80%) coupled with forced air cooling and a novel conductive cooling method provides for a much cooler operation (typically < 55 °C heat sink maximum temperature). Thereby, providing for a much more reliable operation, even at high ambient temperatures. When used in conjunction with the IsoLux Xenon Arc Lamp Housing, it provides for a complete bench top Variable Xenon Power Supply Arc Lamp System for many applications. 300w Variable Power Supply Features Features: Power factor corrected Unique power controls Works with all Xenon short arc lamps Built in circuit breaker Over temperature control Large operating range 125w to 300w
