Automatic packaging machine DPH260

rotarysolidsfor capsules

. Rotary sealing high-speed Blister Machine . The working area is in cantilever construction. Separation of drive and operating zones are in compliance with pharmaceutical requirements. . Accommodates forming material reels of up to 600mm in diameter and a waste material trimming cutter, which allows production runs uninterrupted for approximately 90 minutes, therefore, reducing the material replacement frequency. . Equipped with integrated forming material splicer to enhance efficiency during material replacement. . The upper and lower plates adopt the contact heating method that significantly reduces the forming temperature. Thus the shrinkage, deforming of packaging material and power consumption are minimized. . Equipped with automatic format locking, the positioning system achieves extremely straightforward format changeover . Window frame type no-waste-trimming cutter saves packaging materials. . Adopts transverse cutter, which easily collects its blister card and rejects faulty blister. . All the main parts are made of premium stainless steel and alu alloy material and machined by advanced high-precision CNC tooling machines. . Can be connected to subsequent machines, e.g., High-Speed Cartoners, Stretch-Banding Machine, and Case Packer, etc., to form a whole pharmaceutical packaging line. Main Technical Parameters Max. Forming Area: 250×250mm Max Forming Depth: 12mm Material: Max. width 265mm Machine Power: 16.7kw
