Automatic packaging system DPP260H3 (alu-pvc-alu)

intermittent-motionform-fill-sealfor medicine

This Blister Packaging Machine adds one tropical alu forming station and a second sealing station to allow the plastic thermoforming blister package to be sealed with formed tropical alu again. The shrinkage of the packaging material is minimized to ensure the synchronization of the blister pocket by means of a double servo-regulated drag system. The use of aluminum offers a nearly complete barrier for water, light, and oxygen, allowing an extended product expiration date. The punch station can adopt the crossing type, the trimming waste is about 1mm between two blisters; it can save more material. Can connect with the Cartoner to form an Automatic Pharmaceutical Packaging Line. Main Technical Parameters Max. Forming Area: 250×140mm Max Forming Depth: 12mm Material: Max. width 265mm Machine Power: 14.6kw
