2-shelf shelving unit REF 32/750-02

mortuarymobilestainless steel

The shelf device serves to storages body trays or coffin plates and is installed directly within a morgue refrigeration unit. The shelf device is to be loaded by a lift and transport truck. The structure consists of rugged stainless steel profiles (Material 1.4301 – ANSI 304) which are equipped on each tier with five carrying rollers of corrosion-resistant material with plastic coating and maintenance-free roller bearings and a locking device. Equipped with 4 heavy duty wheels 2 fixed castors, 2 steerable with break, diameter = 125 mm with special roller bearings, permanently lubricated and maintenance-free which ensure an absolutely noiseless movement. The shelf device will be delivered in single parts and are to be installed on location. TECHNICAL DATA Dimensions W/D/H:2080 x 750 x 985 mm Carrying capacity:max. 400 kg Dead weight:approx. 80 kg
