Air filtration system

activated carbonvacuumfor healthcare facilities

MADE IN TAIWAN WITH CE REPORT and Declaration of Conformity Air Cleaning Vacuum 1. 6-LAYERS Filtration 2. 3-Step Arm+ 1-Step Telescopic with evacuation hood angle adjustable 3. White silicone hood can be sterilized 4. Vertical height up to 3 meters & Horizontal length up to 2.5 meters 5. Evacuation strength adjustable via kn ZX-14 plus 300W (3-Step Arm+ 1-Step Telescopic with evacuation hood angle adjustable) Motor specifications: Brushless DC Motor 1. Power: 300w (max); 0.3degree/hour 2. Voltage: 110v/60Hz 3. Motor speed: 7700 rpm(max) 4. Maximum volume: 5.8 m3/min 6. Maximum flow speed: 140km/h=2333m/min= 38m/sec 7. Maximum suction power: 3000 PA(max) 8. Net weight: 18kgs 9. Main box Dimensions: 33*31*45cm 10. 6 stages Filter specifications: Non-woven washable filter: Washable High fiber cotton filter: Replacement 6-12months MD Activated carbon: Replacement 1-2 years HEPA filtration system(H13): 4+5 installed together; Replacement 1-2 years Photocatalyst Nano silver UV light Philips T5-8W*2: Replacement 1-2 years 11. White silicone hood: Silicone can be sterilized 12. Exact replacement time for filter depends on the situation of the environmental pollution FOR MORE INFO. IN PowerPpoint INTRODUCTION please contact us.
