Data management and tracking system XperTrack®

for medicineweb-basedwireless

XperTrack® allows you to remotely control your cold chain shipments. + Remotely control your cold chain shipments + Prevents drug shortage + Allows you to control shipments integrity + Collects and stores temperature, position, light exposure and shocks data in the internal memory + Alarms are triggered when your products exceed the allowed temperature, light exposure and shocks during shipments + Geo-fencing (user definable) + Instantaneously detect if your shipment has been tampered with display the current position and temperature of your container + Complies with FDA 21 CFR Part 11 Characteristics - Sensor type - 4 wires PT-100 / acceleration / light - flexible - 480 mm (19”) - customized - up to 5000 mm (195”) - sensor size - 1.5 x 8 mm (0.06 x 0.315”) - cross section - 1.77 mm² (0.0027 inch²) - body - -30°C to +60°C - sensor - -200°C to +200°C Accuracy - ±0.1°C Resolution - 0.01°C Memory capacity - 128,000 data points Memory type - non volatile Data sampling rate - - temperature/position 30 sec to 24 hours - user configurable - shocks Instantaneous on event Data update rate - 20 min to 24 h - user configurable (typically 6 hours) Mechanical - - material - Ertacetal - FDA compliant - enclosure - IP-30 - weight - 375 g (13.23 oz) - size - 134/104/28 mm (5.28/4.10/1.10”) Power - 2 x Lithium rechargeable batteries classified UN3091 under IATA DGR section 3.9.2.6 compliant with ICAO/IATA packing instructions 970, user replaceable Antenna - Internal
