Hydraulic patient lift PGR-150 RS

manualfloor-mounted

Stationary lift PGR 150 RS with manual transmission use in health care facilities, at home for moving people with disabilities of a wheelchair or bed to the room,to the bathroom and other rooms. The lift can be rotated at 360 ° and locked in 8 positions.Lowering and lifting of the person is carried by a lever hydraulic jack. Overall height (from min to max) is equal to 1800 mm. Installation of the lift to the floor is done using eight anchor bolts.Technical characteristics:SN: ОР.4.5.1.1 (8ММ.36.03) Lifting capacity kg, not more 125Suspension height, mm min/max 1200/2200Overall dimensions, mm, not more: - width 720(250) - length 1450 - height 2300Weight, kg, not more 40Type - hydraulic
