Swab folding machine, folds automatically gauze swabs (The machine is indispensable for the use of the P100).
Working width -
30 cm
Length of cut -
Minimum : 15 cm
Maximum : 45 cm (optional 66 cm)
Number of tracks -
3 tracks maximum
Possible sizes -
Minimum size of swabs: 5 cm x 5 cm
Maximum size of swabs: 10 cm x 30 cm (optional 15 cm x 30 cm)
All usual or intermediate sizes can be produced on the
machine thanks to easy adjustments.
Folding -
The conventional folding is at 3 plies of the dental type but folds
can be offset for other combinations.
Production -
2 speeds: 1,200 and 1,800 strokes per hour on 3 channels
maximum, i.e. a maximum theoretical production of 5,400 swabs per hour.
Stacking -
Per packets of 5 swabs (optional stacking per packets: 4 or 6 swabs)
Discharge -
By endless belt, reserve: 20 to 60 swabs
Counter of cycles -
5-digit with rapid reset
Motor power -
0,37 kW
Installed electric power -
< 0,6 kVA
