Easy to use one button press on / off button. Efficient 13200 Oscillation per minute cycle
Unique Ergonomic Design
Easy grip design reduced user fatigue
Portable Power Supply
Easy grip handle and Non slip rubber feet offer extra security.
Waterproof full immersion cleaning
Hand-piece hermitically sealed, watertight to IP67 rating, easy to clean and decontaminate
Low Voltage Safety
Operates on safe 40 Volts
Improved Power supply
Reduced overloading via intelligent current limiter. Increased power to hand-piece and updated safety features, easy top mounted power lead, and protected to IP65 wet environment rating. Available in 110V and 240V versions
Light weight and balanced
Hand piece professionally balanced and only weighs 1300g with flexible silicon hood for improved visibility
Unique Blade security
Comprehensive chrome plated blade range with simple Wrench and blade clamp-screw system. Easy blade rotation and fixation
Technical details
Power Supply
Transformer manufactured to: - IEC – EN60742
Output - Saw 40 VDC
Enclosure manufactured to: - IEC529, DIN40050
Protected to - IP65
Protection - Electronic Current Limiting, Device Double Pole Fused
Constructed to - IEC60601-1
Weight - 1.7kg
Input voltage - 230Vac or 110 Vac
Cable - 4.0m fitted
Hand Piece
Motor - DC Permanent magnet
Speed - no load 13200 cycles per min
Current - no load 40Vdc 0.75amp
Typical load - 1.5 amps
Construction - Anodised Aluminium body with 5 bearing sealed mechanism
Protected to - IP67
Noise Level - 37 dB (A) no blade
Vibration Value - 4.12 m/s2
Weight - 1.3kg
