11 channels : SpO2, Pulse rate, Airflow, Respiratory drive (2-CH), Snoring, Body position, CPAP pressure, Patent event, Battery, Recording time. Compliant with the 3rd level of international sleep diagnosis standard.
Excellent Ergonomic Design
Small Size, light weight and low electricity consumption.
3.1 Inch LCD display all parameters and waves in real time.
Automatic on/off setting.
Friendly UI
Record more than 12 hour overnight data.
Display recording time in real time.
Left battery energy is displayed automatically.
Keep up recording from the pause point for the data integrity.
Efficiency and Flexibility
Easy operation, accurate result, meeting the requirement of sleep apnea diagnosis CPAP titration.
TECH DETAILS
Channels - SpO2, Pulse rate, Airflow, Respiratory drive (2-CH), Snoring, Body position, CPAP pressure, Patent event, Battery, Recording time.
Screen - 3.1 inches LCD with backlit
Display - SpO2, Pulse rate, Airflow, Respiratory drive (2-CH), Snoring, Body position, Battery, Date and time.
Language - Chinese, Englishand French
Weight - 350g
Memory - > 12hours data
Power Supply - DC 3V (2XR6 AA)
Dimensions - 139mm (L) x 82mm(W) x 37mm(H)
