Direct, Reverse and Quick NIBP measurement modes
Suitable for adult, pediatric and neonatal patient
Networking capability
Protection function for NIBP over-range
Built-in rechargeable Battery
Technical Specifications
Safety
Meets the requirements of IEC60601
Dimension
Dimension - 330mm (W) x 280mm (H) x 150mm (D)
Operation Environment
Power: AC110~220V, 50/60 Hz
Temperature: 5~40 0C
Humidity: < 80%
Performance Specifications
Display:Resolution:800 x 600
Trace: 9 waveforms
Sweep speed: 6.25, 12.5, 25, 50 mm/sec
Indicator: Alarm indicator, Power indicator, QRS beep and alarm sound
Interface: Net Port
Battery: Rechargeable
Trend time: ~72 hours
Alarm: 3-level audible and visual alarm
Networking: Can be connected to central monitoring system
Recorder: Built-in, thermal array
Resplration
Method: RA-LL impedance
Measurement range: Adult: 1~99 rpm
Pediatric/Neonatal: 1~99 rpm
Resolution: 1 rpm
Accuracy: ±2 rpm
Alarm range: Adult: 1~99 rpm
Pediatric/Neonatal: 1~99 rpm
SpO2
Resolution: 1%
Accuracy: - 80~100% ±2digit
60~79% ±3digit
0~60% unspecified
Alarm range: 0~100%
ECG
5-lead selectable -
Input: 5-lead: RA; LA; RL; LL; C
Lead selection: I; II; III; avR; avL; avF; V
ECG selection: 7 channels
Gain waveform: x0.5; x1; x2; x4
Sweep speed: 12.5mm/s, 25mm/s, 50mm/s
Heart Rate range: Adult: 15~300bpm;
Pediatric/Neonatal: 15~350bpm
Accuracy: ±2bpm or ±2%, whichever is greater
Resolution: 1bpm
Protection: Withstand 4000VAC/50Hz voltage in isolation. Against electro surgical interference and defibrillation
CMRR: 85 dB
Calibration signal: 1mV 5%
Operation modes: Diagnostic, Monitor, Surgery
Bandwidth: 0.05~75 Hz
Alarm range: Adult: 0~300bpm
Pediatrinc/Neonatal: 0~350bpm
