Reinforced frame with double cross braces provide a sturdy support for heavy duty use.
Auxiliary hand brakes offer extra safety.
Four poles motor provides more power and torque.
Optional pneumatic casters and drive wheels.
Patented folding battery tray allows improved portability.
Programmable controller with various choices of different performance to fit various needs of users.
Height adjustable flip-up desk armrests and swing away footrests for easier access.
Optional adjustable mounting bracket for the controller, swing back mounting bracket.
Product Weight:
83 kg / 183 lb
Driving Range:
40 km / 25 mi.
Battery Type -
12V / 22NF x 2 pcs
Motor -
DC 24V , 300W , 2P (Rating) / 1450W (Max)
Max Climbing Angle -
10°
Turning Radius -
66 cm /26"
Ground Clearance -
12 cm / 4.5"
Controller -
PG VSI 70A
Charger -
5A off-board
Total Weight -
83 kg / 183 lb
Front wheel -
9" (2.80/2.50-4) Foam filled tire
Drive Wheel -
12-1/2”x 2-1/4” Foam filled tire
Rear wheel -
12-1/2”x 2-1/4” Foam filled tire
