-Aluminum footplate with flip-up height and angle adjustability for various positions.
-Comfortable 20” wide captain seat with swivel and folding capabilities, headrest and backrest adjustable.
-Unique suspension system with high-density foam seat for a smooth comfortable ride.
-Sophisticated controller coupled with 14” aluminum cast drive wheels offer great maneuverability.
-Fitted with removable anti-tippers for increased safety.
-Optional swingaway footrests and elevating legrests with mounting bracket as a kit.
-Optional power seat elevator.
-Optional full lighting system.
Product Weight:110 kg / 242 lb
Driving Range:32 km / 20 mi.
Max Speed:8 km/h , 5 mph
Battery Type -
12V / 22NF x 2 pcs
Motor -
DC 24V , 240W (Rating) / 950W (Max)
Max Climbing Angle -
12°
Turning Radius -
53 cm / 21"
Ground Clearance -
10 cm / 4"
Controller -
PG nVR2-60A / DY LiNX
Charger -
5A off-board
Total Weight -
110 kg / 242 lb
Front wheel -
210 x 70 PU tire
Drive Wheel -
14" (3.00-8) Foam filled tire
Rear wheel -
14" (3.00-8) Foam filled tire
