3 motors
Electronic adjustments of backrest, height
Trendelenburg and Reverse Trendelenburg functions
Anti-microbial, water proof, flame retardant, air permeable mattress
Removable footrest mattress
Stainless steel handles
Stainless steel waste bin
Lockable, adjustable and removable stainless steel side rails
Removable and Adjustable Polyurethane Leg Supports
Hand control unit
Protective plastic bumpers
Detachable head board
Stainless steelheight adjustable IV Pole
ABS covered sub-frame
Stainless steel accessory rails
Easily cleanable, compact laminate mattress platform
Electrostatic powder coated metal frame
IV pole sockets
Central lockable single castors
TECHNICIAL SPECIFICATIONS
Backrest Angle : 0°-70°
Trendelenburg Angle : 0°-14°
Reverse Trendelenburg Angle : 0°-14°
Castor Diameter : 150 mm
Weight : 93 kg
Mattress Thickness(backrest and pelvic sections) : 8cm - Footrest
Mattress Thickness : 12 cm
Bed Surface : 60 x 168 cm
Underbed Clearance : 17 cm
Power In : max. 3,15A 100V – 240V ~ 50/60 Hz
Electrical Shock Protection : Class I, Type B
Liquid Ingress Protection : IPx66
OPTIONAL ACCESSORIES
Battery Back-up
Lifting Pole
X-Ray Cassette Holder at Backrest
Central Lockable Twin Castors (150 mm)
Accessory Trolley (A 9025)
Manuel CPR
Foot Control Pedal
