Laboratory peristaltic pump LM40A

LM40 micro peristaltic pump is a stepper peristaltic pump driven by high precision stepper motor with adjustable speed and flow rate via speed button or rotary encoder, LCD screen display the current working speed to help users flexibly adjust the speed whenever needed, liquid direction can also be adjusted from CW to CCW or from CCW to CW. Speed 0.1RPM ~ 300/400 RPM Speed resolution ±0.1rpm Flow range 0.03~117 ml/min Foot pedal input Foot switch control start-stop (only the keyboard control mode) Speed signal input Multiple speed signal supported (external control mode only) Direction signal input Multiple direction signal supported (external control mode only) ON/OFF signal input Multiple ON/OFF signal supported (external control mode only) Communication RS485 (Communication control mode only) Power supply DC24V±10% Max Power 18W Working environment Ambient temperature 0～40℃ Relative humidity＜80% non-condensing Dimension (L*W*H) 173×105×96mm Net weight 1.45 Kg Protection level IP31
