1.Based on the new class B of international prEN13060, have 3 pulsating vacuum, Vacuum up to -0.9Bar (-0.09Mpa).Suitable to sterilizing wrap, unwrap, solid, porous, hollow device.
2.Use imported&advancedl6-bit microprocessor,easy to operate. Most suitable for the Dept of Stomatology,Ophthalmology, Surgery and Lab.
3.With B& D test and vacuum test procedures. To test the penetrability.
4.Chamber punched by Stainless Steel (#304, thickness: 2.5mm), together with The jet type of steam generator,self-cleaning ensure the efficient sterilizing.
5.With alarm system for waste water tank, avoid the waste water to enter into the sterilizing circulation, make the sterilizing completely.
6.Precise LED digital display and advanced self-test system ensure you get the working data freely.
7.Double lock door system for safety during operating.
8.with built-in printer .USB optional. The disinfection process data and date automatically print.
Technical parameters
Sterilization level
European Class B standard
Special sterilization
Kill active HV,HBV,BSE and spore
Dry procedure
Strong vacuum drying,the residual humidity<0.2%
Display
Widescreen LED
Test
Bowie&Dick Steam penetration test, vacuum test , Helix test
Safety
Safety valve, Doble Pressure lock Automatic check.
Sterilizing record
Optional USB and printer (internal or external) to record the sterilization process
Water supply system
3L distiller water tank,3L waste water tank
Clean procedure
Automatic clean inside pipe and steam generator
Instrument containers
5 levels with 3 Round trays
