• Flexibility and safety for a wide range of use
• Effective performance in a compact low priming design
• Pressure manometer and température probe port
• High heat exchanger performance
• Sterilization : ETO
Specifications
Heat exchanger effective area 0.02 m2
Heat Exchanger priming volume 30 mL
Equipment priming volume 105 mL
System total volume 135 mL
Crystalloid solution filter pore diameter 0.8 microns
Filtering area crystalloid solution filter 14.5 cm2
Materials
Heat exchanger Anodized Aluminium
Central Valve Polyethilene
