Operating room door QTDM-1
slidingstainless steelwith glass panel

operating room door
operating room door
operating room door
operating room door
operating room door
Add to favorites
Compare this product


Characteristics

Application domain
operating room
Opening type
sliding
Material
stainless steel, with glass panel
Other characteristic
automatic

Description

●Both on-wall type and built-in type are available. The track rail is mounted on/into the wall, of easy installation and good-looking appearance. ● Control system is designed in accordance with the safety requirements of medical electrical system, and also multiform control modes could be adopted according to the hospital requirements, that will not cause electromagnetic interference to other equipments at the same location; ●Security sensors are adopted to automatically detect if there are any obstacles when the door is closing and keep the door opening to ensure the safety of passengers or equipments. ● Whenever obstructions happened during operation, the door will rebound automatically to ensure the safety of passengers. ● Operating quietly and fast, the sound insulation effect is good. Door Leaf Weight : - Max 150kg Door Width: - DW=1070mm~1570mm Opening Speed : - 250~550mm/s (Adjustable) Closing Speed: - 250~550mm/s (Adjustable) Opening Delay Time: - 2~20s (Adjustable) Closing Force: - >70N Manual Open Force: - <100N Power Consumption: - <150W HIGH-TECH PATENTS ●Adopting Ownic exclusive high-tech patents ---National Patent No.: ZL200520014092.5 / ZL 200520014093.X HERMETIZATION ●Ownic meet the highest grade 8 of national standards GB/T 7106-2008, could effectively prevent cross infection and greatly enhanced the hygienic performance of hospitals. ● OT Room or somewhere need high Cleanless requirements.
