Temperature sensor MIS-2500

pressuremedical

Measuring range 0 to 0.07...10 bar Output type Analogue Temp. range [C -40 to +85 Mounting style THT Supplier Pewatron Pressure type Gauge, vacuum Supply voltage [V] 3...5 Temperature compensation Yes Pressure port Axial port „ Features … Factory calibrated and temperature compensated … ±1.3%FS accuracy（20 to 60℃） … 3V or 5V rail to rail ratiometric analog output … Gauge pressure or vacuum type … Pressure range: 1, 5.8, 15, 30, 150 psi & -1000mbar The MIS-2500 is a intelligent pressure sensor which consist of a MEMS piezoresistive pressure sensor and a CMOS sensor interface IC. The interface IC enables easy and precise calibration of resistive bridge sensors via EEPROM. It correct digitally offset、gain and both temperature coefficients. All devices were factory calibrated and temperature compensated. Using MIS-2500 series is easy to get rid of bothersome calibrations and temperature compensations. The MIS-2500 can provide 3V or 5V rail-to-rail ratiometric analog output.
