Oxygen analyzer OxyExtract

for the pharmaceutical industryautomaticmanual

For In-Situ Installation Into Process Gas Streams Measurement range of 0 to 25% O2 ATEX/IECEx approved for Hazardous Area applications Manual or Automatic Actuation Available in 316 Stainless Steel and Hastelloy C22 Tri-clamp and flanged process connections The OxyExtract In-line O2 Measurement Analyzer can measure O2 concentration directly in the process gas stream without the need for complex extractive sampling systems. It is perfectly suited to Safety Critical applications within the Chemical and Pharmaceutical Industries as the sensor can be removed or replaced without exposing the process to ambient air. Proven, Trusted Technology The OxyExtract range of IECEx/ATEX approved retractable In-Line Oxygen Sensors along with the OxyOne Analyser and ACCU Calibration unit, provide a cost-effective solution to meet your process safety requirements. The Primary advantage of the OxyExtract is the ability to measure Oxygen concentration directly in the process gas stream without the need for complex sampling systems ensuring a truly representative sample and the best speed of response. Two basic versions are offered, either manual or automated (pneumatic) insertion and retraction of the sensor probe. The OxyExtract is available in 316 stainless steel and Hastelloy C22 and has a variety of Tri-Clamp and Flange process connections.
