brilliant, non-reflective illumination of the treatment level helps the examining doctor during diagnosis
extended life time - maximum energy efficiency - minimal maintenance
full access to the patient thanks to a maximum floor freedom
Economy
high life expectancy of the light source
low maintenance effort
Safety
protected interior cable management
Room height: 2,700
Length of ceiling connection: 750 mm
Angle of rotation: ~ 370°
Working radius: 1100 mm
Colour of lamp: White
Luminous flux (lm): 550 lm
Light field diameter D10: ~ 130 / 250 mm at 500 / 1.000 mm
Light colour: ~ 4000 ± 200 K
Colour rendering index: > Typ 90 Ra
Life expectancy: > 50,000 h (light source)
Electrical mains: 100 - 240 V, 50 - 60 Hz
Motion control: Turn on/ off, Dimming
Note: Due to measurement and production given data may deviate by approx. -10% to + 20%.
Packaging dimensions
Packaging unit: Unit
Width Box1 0,42 m
Height Box1 0,24 m
Length Box1 0,81 m
Weight Box1 11 kg
