Locoregional hyperthermia system BSD-500

a versatile, fully self-contained treatment system in a mobile configuration or maximum treatment flexibility of superficial tumors within 1” of skin surface Features • Portable • No shielding room needed • FDA Approved for palliative treatment of certain tumors • Delivers both superficial and interstitial hyperthermia Choose from 3 sizes of interchangeable superficial applicators and/or take advantage of up to 24 interstitial antennas for use with brachytherapy. System software provides monitoring and control of up to 8 temperature sensors. Master power control adjustable at the touch of a button. Solid State Generator The BSD 500 microwave hyperthermia system is equipped with a 915 MHz power generator. The solid state generator has 8 channels which can be independently adjusted in phase and amplitude. Up to 24 Interstitial Applicators The 8 channel generator feeds into a 3 way power splitter allowing up to 24 applicators to be connected. Each antenna produces a radiant energy zone that can be arranged to shape a heat zone specific to the tumor. Up to 400 watts The system itself is portable, space efficient and produces up to 400 watts of microwave energy in a single channel mode and up to 60 watts per channel in the eight channel mode. A high resolution touch-screen display is used for treatment planning, setup and monitoring during the procedure. Treats Recurrent Cancer Superficial hyperthermia is used to non-invasively treat recurrent or progressive cancerous tumors located within a few centimeters of the surface of the body. Interstitial hyperthermia is used to treat recurrent or progressive cancerous tumors located below the skins surface.
