Anesthesia ventilator AV-1010

veterinarypneumaticSIMV

It provides the physician with a flexible, simple and easy-to-use ventilator for closed circuit AND semi-close circuit. All the selected patient parameters are clearly visible on large, bright LCD displays. The audio-visual alarm system contains improved alarm features ・・ including alarm mute. The AV-1010 is an advanced, yet easy-to-use anesthesia ventilator. Product Description Portable Veterinary Ventilator For Anesthesia Gas Machine Features： 1.Provide A/C ventilation to the patient in the process of operation or in recovery after the operation. 2.Applied for adult and pediatric and animal 3.Microprocessor controlled ,integrated anesthetic ventilation system 4.7 inch TFT display screen 5.Good air tightness, high reliability Technique Specifications Dimensions: - 43cm*38cm*49cm Weight: - 10kg Working type: - Electronically controlled, pneumatic driven Patient type: - Pediatric, Adult l:E ratio: - 4:1-1:8 Adjustment range: - 1-100bpm Under IPPV and Manual mode: - 4~65bpm Under SIMV: - 1-40bpm Monitoring: - VT, MV, BPM, Paw, FiO2, PEEP, Respiratory Frequency, l:E ratio, Ppeak Waveform: - Pressure- time, Flow- time Power: - AC 220V±10%, 50HZ±2%, built-in battery > 2hrs(rechargeable) 12V Inspiratory time (Tl) (at SIMV) - Adjustment range:0.2 s 〜6.0 s (the limit of l:E ratio< 4) Pressure trigger: - —20 cmH20 〜0 cmH20 Pressure limit: Patient airway pressure range: - -2KPa 〜10KPa Airway pressure monitoring range: - 0〜10KPa Safety valve pressure limit: - 6Kpa Alarm: - High(low) pressure alarm, High(Low) MV alarm, AC power lost alarm Accessories: Oxygen sensor
